The 2022 Launch continues the legacy of a truly remarkable bike. This bike is still one of the best value priced models in the market, hands down, year after year. Available in Gloss Galaxy Green, Matte Storm Grey, and Gloss Iridescent Black colorways, the Launch pairs its great color selection with even better components.

The Launch is equipped with both a sealed integrated headset and sealed Mid bottom bracket, which drastically improves performance and virtually eliminates maintenance of these components. Combined with a parts package that includes Kink Stryker forks, Kink T875 8.75” bars, and Mission Triumph 3pc tubular chromoly cranks, this bike is a rookies dream.

Model Year	2022
Top Tube	20.25"
Rear Triangle	13.25"
Head Tube	75
Stand Over	8.75"
BB Height	11.6"
Frame	Launch
Material	Steel
Fork	Kink Stryker Fork 4130 Chromoly Steerer Tapered Fork Legs
Fork Offset	32mm
Compression Bolt Size	24
Handlebars	Kink T875 Bar 8.75" 100% Hi-Ten Steel
Bar Style	2 Piece
Bar Rise	8.75"
Grips	Kink Paragon Grips
Grip Style	Flangeless
Bar Ends	Kink Thrust
Bar End Size	31
Stem	Kink Bold HRD 50mm
Stem Style	Top Load
Stem Rise	32mm
Stem Reach	50mm
Headset	Mission Sealed Integrated (41.8 x 45)
Headset Style	Integrated
Brake Lever	Mission Token
Lever Orientation	Right
Cable Type	Linear
Brakes	Mission Cease V2
Frame Brake Style	Welded
Cranks	Mission Triumph 3pc Tubular Chromoly 170mm - 8 Spline
Crank Style	3pc
Crank Length	170mm
Drive Side Option	RHD
Spindle Size	19mm
Spindle Splines	8
Bottom Bracket	Sealed Mid 19mm
Bottom Bracket Style	Mid
Pedals	Kink Hemlock Pedals
Pedal Size	9/16"
Chain	Mission 410
Chain Style	410
Sprocket	Mission Rank 25T
Sprocket Size	25t
Hubs	Mission Covert Unsealed 3/8" Axle / Mission Function Semi-Sealed Cassette 14mm
Driver	9 Tooth
Spoke Holes	36
Spoke Style	J Bend
Rims	Mission X7 / Mission X7
Rim Wall	Single Wall
Wheel Size	20"
Seat	Mission Warsaw Combo
Seat Style	Combo
Seat Size	Fat
Seat Post	Mission Combo Steel Post
Post Diameter	25.4mm
Tires	Kink Sever 2.4
Bead Type	Wire
Tire Size	20x2.4
PSI Rating	60
Valve Type	Schrader
Pegs	None
