Made for your growing BMX racer, the Redline MX Expert XL is top of class for value and quality. Aluminum alloy rims, Vee Speedster 20 × 1.6 inch front and 20 × 1.4 inch rear tires, Redline premium aluminum frame, and integrated head tube all come together to make the Redline MX Expert XL lightweight and easy to maneuver. Fit riders 5’2” to 5’6”.

Specs:

BIKE FRAME 6061 Alloy w/Integrated Headtube
BIKE FORK RL Race Hi-Ten w/ Tapered legs
BIKE HEADSET Integrated 1 1/8"
BIKE CRANKS Race Aluminum 3pc, 170mm
BIKE SPROCKET 39t, Alloy
BIKE BOTTOM BRACKET Euro
BIKE COGSET 14t
BIKE CHAIN KMC Z410
BIKE FRONT HUB Redline Aluminum
BIKE REAR HUB RL Aluminum Flip-Flop
BIKE SPOKES 14g Steel
BIKE RIMS Alloy Race 20 x 1.5, 36h
BIKE TIRES Vee Speedster (F)20 x 1.6" / (R)20 x 1.4"
BIKE BRAKE LEVERS Tektro
BIKE PEDALS RL Race 9/16" PC pedal
BIKE HANDLEBAR RL Race 6.5" Rise / 12° Back / 1° Up
BIKE GRIPS Redline Hex expert w/plugs
BIKE STEM RL Hollow Point Aluminum 1 1/8" threadless
BIKE SEAT Pivotal Race
BIKE SEATPOST Pivotal 26.8
BIKE BRAKES Tektro BX-1 Linear

Frame Size	20"
Rider Height	-
Bike Top Tube Length	20.0 "
Bike Head Angle	73.0 °
Bike Seat Angle	69.0 °
Bike Chain Stay Length	13.8 "
Bike Bb Height	11.2 "
Bike Stem Length	50.0 mm
Bike Handlebar Width	26.0 "
Bike Crank Length	170.0 mm
